iOS实现刻度尺,可移动刻度尺,并取得当前对应的刻度值。

本文章,技术意义不大,主要是我想写个文章让特定的人知道我做过iOS开发;

这是以前项目里的代码,直接拿出来!

要做的功能如图:

下面是代码:

 KADRuler.h

#import <UIKit/UIKit.h>

@interface KADRuler : UIView

-(instancetype)initWithFrame:(CGRect)frame fromNumber:(NSInteger)fromNum toNumber:(NSInteger)toNum;
///左边或者右边的空白
@property(nonatomic, assign, readonly)CGFloat sideSpace;
///根据刻度值取它的偏移
-(CGFloat)getScaleOffsetByNumber:(NSInteger)number;
///根据偏移取对应的刻度值
-(NSInteger)getNumberByOffset:(CGFloat)offsetX;
@end

 KADRuler.m

#import "KADRuler.h"

@interface KADRuler()
{
    NSInteger startNum, endNum;
    CGFloat space, lrSpace;
}
@end
@implementation KADRuler

-(instancetype)init
{
    CGRect frame = CGRectMake(0, 0, W_WIDTH, 50);
    return [self initWithFrame:frame];
}

-(instancetype)initWithFrame:(CGRect)frame
{
    return [self initWithFrame:frame fromNumber:0 toNumber:100];
}

-(instancetype)initWithFrame:(CGRect)frame fromNumber:(NSInteger)fromNum toNumber:(NSInteger)toNum
{
    space = 8.0;
    lrSpace = space*3;
    startNum = fromNum;
    endNum = toNum;
    if (endNum<startNum) {
        startNum = 0;
        endNum = 100;
    }
    if(frame.size.height<=0){ frame.size.height = 50; }
    frame.size.width = (endNum-startNum)*space + lrSpace*2;
    self = [super initWithFrame:frame];
    if (self) {
        self.backgroundColor = [UIColor whiteColor];
    }
    return self;
}

-(CGFloat)sideSpace
{
    return lrSpace;
}

-(CGFloat)getScaleOffsetByNumber:(NSInteger)number
{
    if (number<startNum) {
        return 0;
    }
    CGFloat x = lrSpace + space*(number-startNum);
    return x;
}

-(NSInteger)getNumberByOffset:(CGFloat)offsetX
{
    offsetX += 0.05; //增加偏移补偿量,如不增加,则在4/5/5s/6Plus会有边界值显示错误bug
    NSInteger num = (offsetX - lrSpace)/space + startNum;
    return num;
}

-(void)drawRect:(CGRect)rect
{
    CGFloat r,g,b,a;
    UIColor *color = [UIColor colorWithRgbToUIColor:@"898989"];
    [color getRed:&r green:&g blue:&b alpha:&a];
    CGContextRef context = UIGraphicsGetCurrentContext();
    // 设置线的粗细
    CGContextSetLineWidth(context, 1.0);
    CGFloat x = lrSpace, y=0;
    //设置字体
    UIFont *font = [UIFont systemFontOfSize:13.0];
    for (long i=startNum; i<=endNum; i++) {
        // 设置线的颜色及透明度
        CGContextSetRGBStrokeColor(context, r, g, b, a);
        // 开始点
        CGContextMoveToPoint(context, x, 0.0);
        //结束点
        y = i%5==0?25:15;
        CGContextAddLineToPoint(context, x, y); //22
        //开始一条线
        CGContextStrokePath(context);
        //
        if (i%10==0) {
            //设置矩形填充颜色:红色
            CGContextSetRGBFillColor (context, 34.0/255.0, 34.0/255.0, 34.0/255.0, 1.0);
            //在指定的矩形区域内画文字
            NSString *num = [NSString stringWithFormat:@"%ld", i];
            CGSize size = [num sizeWithFont:font];
            [num drawInRect:CGRectMake(x-size.width/2-0.5, y+3, size.width, size.height) withFont:font];
        }
        //
        x += space;
    }
}


@end

 KADRulerControl.h

#import "KADUIControl.h"

@interface KADRulerControl : KADUIControl
///自定义范围初始化
-(instancetype)initWithFrame:(CGRect)frame fromNumber:(NSInteger)fromNum toNumber:(NSInteger)toNum;
///当前刻度值
@property (nonatomic, assign)NSInteger SelectedScale;
///最小可用刻度
@property(nonatomic, assign)NSInteger minNumber;
///最大可用刻度
@property(nonatomic, assign)NSInteger maxNumber;
@end

KADRulerControl.m

#import "KADRulerControl.h"
#import "KADRuler.h"

@interface KADRulerControl()<UIScrollViewDelegate>
{
    UIScrollView *_scro;
    KADRuler *ruler;
    NSInteger selectedNumber;
    NSInteger startNum, endNum;
    BOOL isBusy;
}
@end
@implementation KADRulerControl

-(instancetype)init
{
    CGRect frame = CGRectMake(0, 0, W_WIDTH, 50);
    return [self initWithFrame:frame];
}

-(instancetype)initWithFrame:(CGRect)frame
{
    return [self initWithFrame:frame fromNumber:0 toNumber:100];
}

-(instancetype)initWithFrame:(CGRect)frame fromNumber:(NSInteger)fromNum toNumber:(NSInteger)toNum
{
    if (toNum<fromNum) {
        fromNum = 0;
        toNum = 100;
    }
    self = [super initWithFrame:frame];
    if (self) {
        self.minNumber = fromNum;
        self.maxNumber = toNum;
        _scro = [[UIScrollView alloc] init];
        _scro.frame = self.bounds;
        _scro.bounces = NO;
        _scro.showsHorizontalScrollIndicator = NO;
        _scro.showsVerticalScrollIndicator = NO;
        _scro.delegate = self;
        _scro.backgroundColor = [UIColor clearColor];
        _scro.pagingEnabled = NO;
        [self addSubview:_scro];
        //
        startNum = fromNum-50;
        endNum = toNum+50;
        ruler = [[KADRuler alloc]initWithFrame:frame fromNumber:startNum toNumber:endNum];
        [_scro addSubview:ruler marginLeft:0 marginTop:0];
        [_scro setContentSizeWidth:ruler.width];
        //
        [self addSubview:[self createHLine] marginTop:0];
        selectedNumber = (toNum-fromNum)/2;
        self.SelectedScale = selectedNumber;
    }
    return self;
}

-(void)scrollViewDidScroll:(UIScrollView *)scrollView
{
    CGFloat offsetX = scrollView.contentOffset.x;
    selectedNumber = [ruler getNumberByOffset:offsetX + (_scro.width/2.0)];
    //限制最小和最大值
    if(selectedNumber<self.minNumber){
        scrollView.decelerationRate = 0.0;
        scrollView.scrollEnabled = NO;
        CGFloat x = [ruler getScaleOffsetByNumber:self.minNumber];
        x -= (_scro.width/2.0);
        CGPoint offset = scrollView.contentOffset;
        offset.x = x;
        [scrollView setContentOffset:offset animated:NO];
        scrollView.scrollEnabled = YES;
        scrollView.decelerationRate = UIScrollViewDecelerationRateNormal;
    }else if(selectedNumber>self.maxNumber){
        scrollView.decelerationRate = 0.0;
        scrollView.scrollEnabled = NO;
        CGFloat x = [ruler getScaleOffsetByNumber:self.maxNumber];
        x -= (_scro.width/2.0);
        CGPoint offset = scrollView.contentOffset;
        offset.x = x;
        //scrollView.contentOffset = offset;//不能马上停止
        [scrollView setContentOffset:offset animated:NO];//可马上停止
        scrollView.scrollEnabled = YES;
        scrollView.decelerationRate = UIScrollViewDecelerationRateNormal;
    }
    [self ExecActionBlock:self andTag:selectedNumber andData:nil];
}


-(NSInteger)SelectedScale
{
    return selectedNumber;
}

-(void)setSelectedScale:(NSInteger)SelectedScale
{
    selectedNumber = SelectedScale;
    CGFloat offsetX = [ruler getScaleOffsetByNumber:selectedNumber];
    offsetX -= (_scro.width/2.0);
    [_scro setContentOffsetX:offsetX];
}

-(UIView*)createHLine
{
    UIView *v = [[UIView alloc]initWithFrame:CGRectMake(0, 0, 1, 58)];
    v.backgroundColor = [UIColor colorWithRgbToUIColor:@"fc2d2d"];
    return v;
}

/*
// Only override drawRect: if you perform custom drawing.
// An empty implementation adversely affects performance during animation.
- (void)drawRect:(CGRect)rect {
    // Drawing code
}
*/

@end

KADBMICalculatorVC.m

//
//  KADBMICalculatorVC.m
//  KADOnlinePharmacies
//
//  Created by envon on 15-4-25.
//  Copyright (c) 2015年 360KAD. All rights reserved.
//

#import "KADBMICalculatorVC.h"
#import "KADRulerControl.h"
#import "KADBMIResultVC.h"
#import "KADGuidePageService.h"

@interface KADBMICalculatorVC ()<UIScrollViewDelegate>
{
    CGFloat startY;
    UIScrollView *_scro;
    UILabel *labN2,*labN1;
    KADRulerControl *ruler1,*ruler2;
}
@end

@implementation KADBMICalculatorVC

- (void)viewDidLoad {
    [super viewDidLoad];
    startY = [super getStartY];
    self.view.backgroundColor = [UIColor colorWithRgbToUIColor:@"eeeeee"];
    KADNavigationBar *navBar = [super setNavigationBarWithTitle:@"BMI计算器" andHasBackButton:YES];
    [navBar.contentView addSubview:[self createLine] marginLeft:0 marginBottom:0];
    __weak KADBMICalculatorVC *me = self;
    CGFloat space = Fit750(20);

    //=========== 右上角“更多”选项按钮
    UIButton *rightBarBtn = [super createRMenuWithTag:222];
    rightBarBtn.backgroundColor = [UIColor clearColor];
    [navBar.contentView addSubview:rightBarBtn];

    _scro = [[UIScrollView alloc] init];
    _scro.frame = CGRectMake(0, startY, W_WIDTH, self.view.height-startY);
    _scro.bounces = NO;
    _scro.showsHorizontalScrollIndicator = NO;
    _scro.showsVerticalScrollIndicator = NO;
    _scro.delegate = self;
    _scro.backgroundColor = [UIColor clearColor];
    [self.view addSubview:_scro];

    /**
     *
     * 身高
     */
    /** 默认身高 */
    NSInteger defaultHeight = 170;
    UIView *v1 = [[UIView alloc]initWithFrame:CGRectMake(0, 0, Fit750(750), Fit750(290))];
    v1.backgroundColor = [UIColor whiteColor];
    [_scro addSubview:v1 marginLeft:0 marginTop:space];

    ruler1 = [[KADRulerControl alloc]initWithFrame:CGRectMake(0, 0, W_WIDTH-2*space, Fit750(180)) fromNumber:30 toNumber:300];
    ruler1.layer.borderColor = [UIColor colorWithRgbToUIColor:@"cbcbcb"].CGColor;
    ruler1.layer.borderWidth = KAD_ONE_POINT_WIDTH;
    ruler1.SelectedScale = defaultHeight;
    [ruler1 setActionBlock:^(id handle, NSInteger tag, id data) {
        [me setN1:tag];
    }];
    [v1 addSubview:ruler1 marginLeft:space marginBottom:space];
    //
    UILabel *lab11 = [UILabel labelWithFrame:CGRectZero text:@"身高" fontSize:14 textRgbColor:@"222222" bgRgbColor:@"clear" align:NSTextAlignmentCenter];
    UILabel *lab12 = [UILabel labelWithFrame:CGRectZero text:@"CM" fontSize:14 textRgbColor:@"222222" bgRgbColor:@"clear" align:NSTextAlignmentCenter];
    [lab11 autoSizeWithFont]; [lab12 autoSizeWithFont];
    [v1 addSubview:lab11 marginLeft:space marginTop:Fit750(44)];
    [v1 addSubview:lab12 marginRight:space marginTop:Fit750(44)];
    //
    labN1 = [UILabel labelWithFrame:CGRectZero text:[NSString stringWithFormat:@"%zd",defaultHeight] fontSize:14 textRgbColor:@"2d8ff3" bgRgbColor:@"clear" align:NSTextAlignmentCenter];
    labN1.font = [UIFont boldSystemFontOfSize:16];
    [labN1 autoSizeWithFont];
    [v1 addSubview:labN1 marginTop:Fit750(40)];

    /**
     *
     * 体重
     */
    /** 默认体重 */
    NSInteger defaultWeight = 70;
    UIView *v2 = [[UIView alloc]initWithFrame:CGRectMake(0, 0, Fit750(750), Fit750(290))];
    v2.backgroundColor = [UIColor whiteColor];
    [_scro addSubview:v2 atBottomFrame:v1.frame top:space left:0];

    ruler2 = [[KADRulerControl alloc]initWithFrame:CGRectMake(0, 0, W_WIDTH-2*space, Fit750(180)) fromNumber:0 toNumber:300];
    ruler2.layer.borderColor = [UIColor colorWithRgbToUIColor:@"cbcbcb"].CGColor;
    ruler2.layer.borderWidth = KAD_ONE_POINT_WIDTH;
    ruler2.SelectedScale = defaultWeight;
    [ruler2 setActionBlock:^(id handle, NSInteger tag, id data) {
        [me setN2:tag];
    }];
    [v2 addSubview:ruler2 marginLeft:space marginBottom:space];
    //
    UILabel *lab21 = [UILabel labelWithFrame:CGRectZero text:@"体重" fontSize:14 textRgbColor:@"222222" bgRgbColor:@"clear" align:NSTextAlignmentCenter];
    UILabel *lab22 = [UILabel labelWithFrame:CGRectZero text:@"KG" fontSize:14 textRgbColor:@"222222" bgRgbColor:@"clear" align:NSTextAlignmentCenter];
    [lab21 autoSizeWithFont]; [lab22 autoSizeWithFont];
    [v2 addSubview:lab21 marginLeft:space marginTop:Fit750(44)];
    [v2 addSubview:lab22 marginRight:space marginTop:Fit750(44)];
    //
    labN2 = [UILabel labelWithFrame:CGRectZero text:[NSString stringWithFormat:@"%zd",defaultWeight] fontSize:14 textRgbColor:@"2d8ff3" bgRgbColor:@"clear" align:NSTextAlignmentCenter];
    labN2.font = [UIFont boldSystemFontOfSize:16];
    [labN2 autoSizeWithFont];
    [v2 addSubview:labN2 marginTop:Fit750(40)];

    /**
     *
     *  计算按钮
     */

    UIButton *btnCount = [UIButton buttonWithFrame:CGRectMake(0, 0,Fit750(709) ,Fit750(88)) Title:@"马上计算" titleFont:[UIFont systemFontOfSize:Fit320(15)] titleColor:[UIColor whiteColor] bgColor:[UIColor colorWithRgbToUIColor:@"2d8ff3"] borderWith:0 borderColor:[UIColor clearColor] cornerRadius:4];
    [btnCount addTarget:self action:@selector(tapCount) forControlEvents:UIControlEventTouchUpInside];
    [_scro addSubview:btnCount atBottomFrame:v2.frame top:space];

    /**
     *
     *  底部提示框
     */

    UIView *tips = [[UIView alloc]initWithFrame:CGRectMake(0, 0, Fit750(709), 80)];
    tips.backgroundColor = [UIColor colorWithRgbToUIColor:@"fafafa"];
    tips.layer.cornerRadius = 3;
    [_scro addSubview:tips atBottomFrame:btnCount.frame top:space left:0];

    NSString *str = @"<font color='#898989'><b>BMI科普:</b><br>BMI指数(身体质量指数,简称体质指数又称体重指数,英文为Body Mass Index,简称BMI),是用体重公斤数除以身高米数平方得出的数字,是目前国际上常用的衡量人体胖瘦程度以及是否健康的一个标准。备注:BMI计算适用于成人(18岁以上),不包括运动员及孕产妇。</font>";
    RTLabel *rtLabel = [[RTLabel alloc] initWithFrame:CGRectMake( 0,0 ,tips.width-space*2, 0)];
//    rtLabel.lineSpacing = Fit320(8);
    [rtLabel setText:str];
    rtLabel.font = [UIFont systemFontOfSize:Fit320(12)];
    [rtLabel fitSize];
    [tips addSubview:rtLabel marginLeft:space marginTop:space];

    [tips setHeight:CGRectGetMaxY(rtLabel.frame) + space];
    [_scro setContentSizeHeight:CGRectGetMaxY(tips.frame) + 20];
}

-(void)viewDidAppear:(BOOL)animated
{
    [super viewDidAppear:animated];
    //引导页
    [KADGuidePageService showInViewController:self];
}

///点击计算按钮
-(void)tapCount
{
    NSInteger num1 = ruler1.SelectedScale;//身高
    NSInteger num2 = ruler2.SelectedScale;//体重
//=========== 测试用提醒
//    [self alertShow:[NSString stringWithFormat:@"身高:%ld, 体重:%ld",num1, num2]];
    KADBMIResultVC *bmiResult = [[KADBMIResultVC alloc]init];
    bmiResult.num1 = num1;
    bmiResult.num2 = num2;
    bmiResult.backAnimated = YES;
    bmiResult.hidesBottomBarWhenPushed = YES;
    [self.navigationController pushViewController:bmiResult animated:YES];
}

-(void)setN1:(NSInteger)number
{
    CGPoint p = labN1.center;
    labN1.text = [NSString stringWithFormat:@"%ld", (long)number];
    [labN1 autoSizeWithFont];
    labN1.center = p;
}

-(void)setN2:(NSInteger)number
{
    CGPoint p = labN2.center;
    labN2.text = [NSString stringWithFormat:@"%ld", (long)number];
    [labN2 autoSizeWithFont];
    labN2.center = p;
}

-(UIView*)createLine
{
    UIView *imgV = [[UIView alloc]initWithFrame:CGRectMake(0, 0, Fit1125(1125), KAD_ONE_POINT_WIDTH)];
    imgV.backgroundColor = [UIColor colorWithRgbToUIColor:@"cbcbcb"];
    return imgV;
}

- (void)didReceiveMemoryWarning {
    [super didReceiveMemoryWarning];
    // Dispose of any resources that can be recreated.
}

/*
#pragma mark - Navigation

// In a storyboard-based application, you will often want to do a little preparation before navigation
- (void)prepareForSegue:(UIStoryboardSegue *)segue sender:(id)sender {
    // Get the new view controller using [segue destinationViewController].
    // Pass the selected object to the new view controller.
}
*/

@end

-----------------------------------END


发布评论
IT虾米网

微信公众号号:IT虾米 (左侧二维码扫一扫)欢迎添加!

iOS判断消息推送开关详解
你是第一个吃螃蟹的人
发表评论

◎欢迎参与讨论,请在这里发表您的看法、交流您的观点。
